I. Brief Introduction of sf6 gas transformer

The Test Transformer calls the booster, it is the basic test equipment used by the power station, supplying and distributing the electrical power system and the scientific research unit. Which used in the insulated intension test on all kinds of electrical products, electrical equipments and insulated materials, testing the insulated level of products, discovering the insulated objection of quizzee, scaling the capacity burdened voltage

II.Structure of sf6 gas transformer

They make up of the high quality cold rolling silicon steel piece by HZQ alternating current test transformer, HYQ-JZ alternating and direct current amphibious light high voltage test transformer. The winding is the concentric pagoda  and multilayer cylindrical type, low-voltage winding in inner, high-voltage winding in outside; Outer cover is portable which has characteristics, such as volume smallness, weight light, the shape prettiness and move convenience and so on.

III.sf6 gas transformer Principle of Work

Connecting the control unit (it is the supplementary equipment of test transformer, detailed see the explaining book) with work frequency 220V (above 10KVA with 380V), adjusting 0-220V/380V voltage input to HZQ (YQ-JZ) test transformer primary winding through autotransformer. According to the principle of electromagnetic influence, the secondary (high voltage) winding may gain the same multiple voltage value than the primary winding with the circle rated that is the high frequency voltage of work frequency. It can obtain the direct current high frequency voltage after commuted by high frequency voltage silicon stack and filtrated by capacitor, among whose amplitude value is the 2 times value of work frequency.

This series product divides into three kinds: the alternating current, the alternating and direct current , meanwhile, may connecting alternating current, he alternating and direct current with 200V switch to form series excitation transformer.

IV.Technical Parameters of sf6 gas transformer.
